Digital No-Flow Timer (DNFT) premier

The Revolutionary Digital No-Flow Timer for Compressor Lube Systems
DNFT performs monitoring and shutdown functions like No-Flow, Low-Flow or Excessive-Flow for Divider-Block
Lubrication
Systems. The DNFT is a totally enclosed solid state electronic device for detecting Slow-Flow and No-Flow on in-line
progressive
lubrication systems. The Digital No-Flow Timer incorporates a crystal oscillator to accurately monitor the cycle time
of the
lubrication system enabling precision timed shutdown capability. An internal Lithium battery powers it, which is easily
replaceable.
The Digital No-Flow Timer is an ISO 9001 certified product and the ISO certification can be viewed here. All Digital
No-Flow
Timers also come with a 3 year warranty.
The DNFTs come in three models to switch voltages up to 240 VDC:

Monitors Movement of Divider Valve Piston
监测分配器柱塞的运动
Closed Loop or Open Loop Operation
开式或闭式回路
Installs Directly to Divider Valve
直接安装在分配器上面
Not Affected By Temperature or Viscosity
不受温度和粘度的影响
Requires No External Power
不需要外接电源
LED or LCC Cycle Indicator
带LED或LCC循环指示
Dependable “Timed” Shutdown Protection
可靠的停机保护
Explosion Proof Rated for
防爆等级:
Class 1, Division 1, Groups A,B,C,D
CSA Approved
通过CSA防爆认证 CE Approved 和CE防爆认证

DNFT LED model


DNFT LCC model


DNFT PRG model

Downloads (Product Data Sheets)
Instruction guide for each model of the DNFT is available for download. These files are in Adobe Acrobat (.pdf)
format. These
product data sheets are available to be printed out and reviewed for your convenience. You must view these
downloads using
DNFT-T0 -PRX Part no : 000172, serial number : DL 12571, rated : 2.5VA/240VDC
Slow Internet Connections
DNFT LED 2 mins
DNFT LED 2 mins
DNFT LED 2 mins
DNFT LED 2 mins
DNFT LED 2 mins
DNFT LED-PS 3 mins
DNFT LED-PS 3 mins
DNFT LED-PS 3 mins
DNFT LED-PS 3 mins
DNFT LED-PS 3 mins
DNFT LCC 45 secs
DNFT LCC 45 secs
DNFT LCC 45 secs
DNFT LCC 45 secs
DNFT LCC 45 secs
DNFT LCC 2 mins
DNFT LCC 2 mins
DNFT LCC 2 mins
DNFT LCC 2 mins
DNFT LCC 2 mins
DNFT LCC 3 mins
DNFT LCC 3 mins
DNFT LCC 3 mins
DNFT LCC 3 mins
DNFT LCC 3 mins
DNFT LCC 255 secs
DNFT LCC 255 secs
DNFT LCC 255 secs
DNFT LCC 255 secs
DNFT LCC 255 secs
DNFT PRG 20 to 255 secs
DNFT PRG 20 to 255 secs
DNFT PRG 20 to 255 secs
DNFT PRG 20 to 255 secs
DNFT PRG 20 to 255 secs
DNFT PRG 20 to 255 secs
DNFT PRG-PS 20 to 255 secs
DNFT PRG-PS 20 to 255 secs
DNFT PRG-PS 20 to 255 secs
DNFT PRG-PS 20 to 255 secs
DNFT PRG-PS 20 to 255 secs
DNFT PRG-PS 20 to 255 secs
DIGITAL NO－FLOW TIMER，
MODEL：DNFT－PRG，
